IMS3214-8P6S Industrial Managed Switch are fully managed L2 switches, adopt store-forward architecture, fan-less and energy-saving design, with 8*10/100/1000Base-T with POE af/at port and 6*1.25G/155M SFP fiber port. Full-series design with protection against lightning,anti-static and operate in -40°C~85°C for harsh environments; such as industrial automation, public security, power system, intelligent transportation systems (ITS), shipping, mining ,water conservancy and oil fields.
The twisted-pair port also injects power down the cable, allowing a remote Power over Ethernet Device to operate without the need of any additional power source. All Power over Ethernet Powered Devices (IEEE 802.3af/at complaint) are supported, as the Power Sourcing Equipment (PSE) device can deliver a full 15.4W / 30W of power to the remote PD device.
Technical Specifications
Standards
IEEE802.3 10BASE-T; IEEE802.3u 100Base-TX
IEEE802.3ab 1000Base-T; IEEE802.3z 1000Base-X
IEEE802.3x Flow control and back pressure; IEEE802.1Q VLAN
24%
Mô tả
IMS3214-8P6S Industrial Managed Switch are fully managed L2 switches, adopt store-forward architecture, fan-less and energy-saving design, with 8*10/100/1000Base-T with POE af/at port and 6*1.25G/155M SFP fiber port. Full-series design with protection against lightning,anti-static and operate in -40°C~85°C for harsh environments; such as industrial automation, public security, power system, intelligent transportation systems (ITS), shipping, mining ,water conservancy and oil fields.
The twisted-pair port also injects power down the cable, allowing a remote Power over Ethernet Device to operate without the need of any additional power source. All Power over Ethernet Powered Devices (IEEE 802.3af/at complaint) are supported, as the Power Sourcing Equipment (PSE) device can deliver a full 15.4W / 30W of power to the remote PD device.
Technical Specifications
IEEE802.3ab 1000Base-T; IEEE802.3z 1000Base-X
IEEE802.3x Flow control and back pressure; IEEE802.1Q VLAN
IEE802.3af/at POE
IEEE802.1w RSTP
IEEE802.1s MSTP
IEEE802.1d STP
ESD protection
EFT protection
Power range: DC48-57V
Output power / working time management
6-PIN Removable Terminal Block
Overload voltage protection
Overload current protection
Reverse Polarity protection
Lightning protection:6KV
ESD: 8~15KV
Software Feature
