Interface

Optical interface: 100Mbps (Interface type: SC, ST, FC and SFP Slot  are available)

Network interface: 10/100Mbps self-adaptation, Full/Half duplex mode,support MDI/MDI-X. normal transmission distance 0-100m; long distance mode 0-350m.

DIP switch:

LED indicator: PWR, Link, 10/100Base-T

Switch Properties

Backboard bandwidth:1Gbps  MAC address table: 1K

Message cache size: 512Kbits

Power Supply

Input voltage: 100~240V AC

Input current: max 30mA

Physical Properties

Housing: metal, IP30 protection

Dimension: 125x109x32mm

Weight: 430g

Installation mode: desktop installation, wall-mounted installation

Environmental Constraint

Working temperature: -20 ~ 60°C(-4 ~ 140°F)

Storage temperature: -40 ~ 85°C(-40 ~ 185°F)

Environment relative humidity: 5 ~ 95% (non-condensing)

Standards and certification

Electromagnetic interference (EMI): FCC Part 15/CISPR22(EN55022): Class A

Electromagnetic sensibility (EMS):

IEC61000-4-2 (ESD) Class 3, IEC 61000-4-3 (RS) Class 3, IEC 61000-4-4 (EFT) Class 2, IEC 61000-4-5 (Surge) Class 3, IEC 61000-4-6 (CS) Class 3

Vibration resistance: IEC60068-2-6

Impact resistance: IEC60068-2-27

Free falling: IEC60068-2-32

Note: Please visit Wintop official website to check the latest certifications.

MTBF (mean time between failures)

Time: 500000h

Quality Warranty

3 years
