H805GPFD is a 16 port GPON interface card of Huawei OLT, provide GPON service access from ONT. GPFD can maximum access 16*128 GPON subscribers. GPFD has different part number like H80D00GPFD01, H80D00GPFD02 etc, but basically you only need to identity H802GPFD, H803GPFD, H805GPFD version, and with B+ or C+/C++ SFP module.
Tech Specs
Front Pannel
Specification
Service ports
GPON Port
16-GPON Port
GPON SFP Module Specification
Type
B+ Module : One-fiber bi-directional optical module, class B+ C+ Module : One-fiber bi-directional optical module, class C+ C++ Module:One-fiber bi-directional optical module, class C++
H802GPFD : Static: 45 W, Maximum: 73 W H803GPFD : Static: 39 W, Maximum: 61 W H805GPFD : Static: 26 W, Maximum: 50 W
Maximum Frame Size
2004 bytes
Operating temperature
-25°C to +65°C
Q & A
Q: What is the difference between GPFD and GPBD board?
A: The main difference is capacity, GPFD is 16-GPON Port board, GPBD is 8-GPON Port board.
Q: What is the difference between different GPON board?
A:
Board
GPON Type
Port Quantity
Optical Module
Maximum Split Ratio
ONU based shaping
H807GPBD
1G-GPON
8
SFP (Class B+ and Class C+)
1:128
No
H805GPBD H806GPBD
1G-GPON
8
SFP (Class B+ and Class C+)
1:128
Yes
H802GPFD H805GPFD
1G-GPON
16
SFP (Class B+ and Class C+)
1:128
Yes
H806GPBH H807GPBH
1G-GPON
8
SFP (Class B+ and Class C+)
1:128
Yes
H802XGBC
10G-GPON
4
XFP
1:128
Yes
Q:What is the difference between different Huawei H80D00GPFD01, H80D00GPFD02?
A: We don’t suggest you order according to this BOM, this BOM is mostly used for manufacturer producing purpose, Basically choosing GPFD card, we just need to know: 1, H802GPFD, H803GPFD or H805GPFD? 2, with B+ SFP Module or C+ SFP Module?
Q: What is the difference among GPON B+, GPON C+ and GPON C++ transceiver?
A:
B+ Module
C+ Module
C++ Module
Type
One-fiber bi-directional optical module, class B+
One-fiber bi-directional optical module, class C+
One-fiber bi-directional optical module, class C++
Operating Wavelength
Tx: 1490 nm Rx: 1310 nm
Encapsulation Type
SFP
Port Rate
Tx:2.49Gbit/s
Rx:1.24Gbit/s
Tx:2.488Gb/s
Rx:1.244Gb/s
Minimum Output Optical Power
1.50 dBm
3.00 dBm
6.00 dBm
Maximum Output Optical Power
5.00 dBm
7.00 dBm
10.00 dBm
Maximum Receiver Sensitivity
-28.00 dBm
-32.00 dBm
-35.00 dBm
Optical Connector Type
SC/PC
SC/UPC
Optical Fiber Type
Single-mode
Reach
20.00km
Overload Optical Power
-8.0 dBm
-12.0 dBm
-15.0 dBm
Extinction Ratio
8.2 dB
H805GPFD and H807GPBD are most selected items.
Q: Does the GPON SFP Module included in GPFD?
A: Yes, with GPFD board, 16 C+ SFP Module are included for free.
Q: Can I do twice splitting with GPFD?
A: Yes, you can, just make sure the optical power is within the receive side range.
Q: Can I use a 3rd party ONT with GPFD?
A: We don’t suggest so, as the understanding of TR069/OMCI protocol may different between different vendors.
Q: What is the power consumption of GPFD board?
A: Between 45~73W.
Q: How can I check my H805GPFD status by command on MA5683T?
A: The most common status checking command is "display board 0", for details you can refer to GPON board common command guide.
Mô tả
Huawei 16-GPON Port Interface Card with C+ SFP module
Apply to Huawei MA5683T, MA5680T, MA5608T OLT system
Available at 3 versions: H802GPFD, H803GPFD, H805GPFD
Support split ratio 1:128
Transmit Speed: 2.488Gbit/s, Receive Speed: 1.244Gbit/s
Interface Type: SC/PC, SC/UPC
Max Transmit Distance: 20KM
Transmit Wavelength: 1490nm, Receive Wavelength: 1310nm
Standards Compliance: ITU-T G.984.1, ITU-T G.984.2, ITU-T G.984.3, ITU-T G.984.4
C++ SFP Module Optical Power: 6 dBm~10dBm, Receiver sensitivity: -35 dBm
C+ SFP Module Optical Power: 3 dBm~7 dBm, Receiver Sensitivity: -32 dBm
B+ SFP Module Optical Power: 1.5 dBm~5 dBm, Receiver Sensitivity: -28 dBm
H805GPFD is a 16 port GPON interface card of Huawei OLT, provide GPON service access from ONT. GPFD can maximum access 16*128 GPON subscribers. GPFD has different part number like H80D00GPFD01, H80D00GPFD02 etc, but basically you only need to identity H802GPFD, H803GPFD, H805GPFD version, and with B+ or C+/C++ SFP module.
C+ Module : One-fiber bi-directional optical module, class C+
C++ Module:One-fiber bi-directional optical module, class C++
C++: Tx:2.488Gb/s, Rx:1.244Gb/s
C+ Module : 3.00 dBm
C++ Module: 6.00 dBm
C+ Module : 7.00 dBm
C++ Module: 10.00 dBm
C+ Module : -32.00 dBm
C++ Module: -35.00 dBm
C++: SC/UPC
C+ Module : -12.0 dBm
C++ Module: -15.0 dBm
H803GPFD : Static: 39 W, Maximum: 61 W
H805GPFD : Static: 26 W, Maximum: 50 W
Q & A
Q: What is the difference between GPFD and GPBD board?
A: The main difference is capacity, GPFD is 16-GPON Port board, GPBD is 8-GPON Port board.
Q: What is the difference between different GPON board?
A:
(Class B+ and Class C+)
H806GPBD
(Class B+ and Class C+)
H805GPFD
(Class B+ and Class C+)
H807GPBH
(Class B+ and Class C+)
Q:What is the difference between different Huawei H80D00GPFD01, H80D00GPFD02?
A: We don’t suggest you order according to this BOM, this BOM is mostly used for manufacturer producing purpose, Basically choosing GPFD card, we just need to know: 1, H802GPFD, H803GPFD or H805GPFD? 2, with B+ SFP Module or C+ SFP Module?
Q: What is the difference among GPON B+, GPON C+ and GPON C++ transceiver?
A:
Rx: 1310 nm
Tx:2.49Gbit/s
Rx:1.24Gbit/s
Tx:2.488Gb/s
Rx:1.244Gb/s
H805GPFD and H807GPBD are most selected items.
Q: Does the GPON SFP Module included in GPFD?
A: Yes, with GPFD board, 16 C+ SFP Module are included for free.
Q: Can I do twice splitting with GPFD?
A: Yes, you can, just make sure the optical power is within the receive side range.
Q: Can I use a 3rd party ONT with GPFD?
A: We don’t suggest so, as the understanding of TR069/OMCI protocol may different between different vendors.
Q: What is the power consumption of GPFD board?
A: Between 45~73W.
Q: How can I check my H805GPFD status by command on MA5683T?
A: The most common status checking command is "display board 0", for details you can refer to GPON board common command guide.
