Type
JW3208A
JW3208C
Wavelength(nm)
800~1700nm
Detector
InGaAs
Measurement Range (dBm)
-70~+6
-50~+26
Uncertainty
±5%
Calibrated Wavelength(nm)
850,980,1300,1310,1490,1550
Resolution(dB)
0.01
Optical Connector
FC(interchangeable SC,ST) / as well as 2.5mm universal
Power Supply
Alkaline Battery(3 AA 1.5V batteries)
Battery Operating Time
240 h with 1.5V Battery(3)
Operating Temperature(℃)
-10 ~ +60
Storage Temperature(℃)
-25 ~ +70
Relative Humidity
0 to 95% (non-condensing)
Dimension
23.5*16*8cm
Weight
0.5kg
5,800,000₫
2,100,000₫
2,980,000₫
3,300,000₫
3,200,000₫
1,100,000₫
1,400,000₫
630,000₫
900,000₫
950,000₫
Liên hệ
670,000₫
700,000₫
480,000₫
Chat với chúng tôi
10%
21%
30%
4%
Mô tả
- User self calibration function
- Comfortable LCD display and optional backlight LCD display supports night operation
- Power measurements in dBm or mw and insertion loss in dB
- Low battery consumption, more than 240 hours continual operation time for three 1.5V alkaline batteries
- 10 minutes Auto-off function can be activated or deactivated.
SpecificationsType
JW3208A
JW3208C
Wavelength(nm)
800~1700nm
Detector
InGaAs
Measurement Range (dBm)
-70~+6
-50~+26
Uncertainty
±5%
Calibrated Wavelength(nm)
850,980,1300,1310,1490,1550
Resolution(dB)
0.01
Optical Connector
FC(interchangeable SC,ST) / as well as 2.5mm universal
Power Supply
Alkaline Battery(3 AA 1.5V batteries)
Battery Operating Time
240 h with 1.5V Battery(3)
Operating Temperature(℃)
-10 ~ +60
Storage Temperature(℃)
-25 ~ +70
Relative Humidity
0 to 95% (non-condensing)
Dimension
23.5*16*8cm
Weight
0.5kg
