Máy hàn cáp quang ILSINTECH KF4

42,000,000₫ ~~45,600,000₫~~

Tags:

Mô tả

SWIFT KF4 Active Cladding Alignment

Swift KF4 is very versatile and super accurate active cladding alignment fusion splicer that satisfies every aspect of splicing requirement. With slim, yet rugged and extremely light, budget priced Swift KF4 assures users of convenient and stable process as well as high performance. .

l BENEFITS AND FEATURES

Compact, Lightweight and Convenient

▶ Best Active Cladding Alignment fusion splicer with slim and light form factor

l Size : 124(W) × 189(L) × 75(H) mm l Weight : 1.1 kg (Including battery)

l Splicing time : 7 sec l Heating : 13 sec (IS-60 mode, IS-60 sleeve)

▶ With Work Table, maximizing the work efficiency.

Resistance to Shock, Dust and Water

▶ The splicer with high reliability has stable performance even in a harsh environment.

l Shock – Free Fall : 76cm l Waterproof : IPx2 l Dustproof : IP5x

Resistance Wide LCD : 4.3 Inch

▶ Heater Crystal clear and wide 4.3" LCD.

l SPECIFICATIONS

Category	Description
Fiber alignment	IPAAS, Active V-Groove Alignment
Applicable type of fibers	0.25mm, 0.9mm, 2.0mm, 3.0mm, Indoor cable
Fiber count	Single fiber
Applicable fiber dimensions	Cladding diameter: 125㎛ / Coating diameter: 150㎛~3mm
Fiber setting and cleaved length	5mm to 16mm
Splicing modes	Splice mode: 300, Heater mode:100
Typical Splice Loss	SM: 0.02dB, MM: 0.01dB, DS: 0.04dB, NZDS: 0.04dB
Return loss	> 60dB
Splicing Time	Typical 7sec With SM
Splice loss estimate	Available
Sleeve heating time	Typical 13sec with IS-60 mode, IS-60 sleeve
Applicable protection sleeve	40mm,60mm and micro sleeves
Storage of splice result	Date : Up to 5,000 (Image: Up to 5,000 pec)
Tension test	1.96N to 2.25N
Operating condition	Altitude: 5,000m above sea level, Temperature: -10℃~50℃, Humidity: 0~95%, Wind: 15m/s, non-condensing, dust proof, water proof, shock proof
Storage condition	Temperature: -40℃~80℃, Humidity: 0~95%
Dimension	124(W)ｘ189(L)ｘ75(H)mm(Without rubber protector)
Weight	1.1kg(Including battery)
Viewing method and display	Two CMOS cameras and 4,3-inch color LCD monitor
Fiber view and magnification	X/Y : 130X MAX:260X
Power supply	Li-ion Battery(DC 14.8V, 3400mAh), 100 ~ 240V AC Charger
No.of splice cycles with battery	Typical 200 cycles
Electrode lifetime	More than 21,000 times
Blade lifetime	75,000 cleaves
Terminals	USB

l STANDARD PACKAGE

Category	Model	Q’ty
Arc Fusion Splicer	KF4	1
Battery Adapter	FY1701000	1
Spare Electrode	EI-24	1pair
Cooling Tray	CT-01(40mm)	1
Instructions for use	-	1
Carrying Case	Soft Case(ILST-SS03 L)	1
Battery	KF-3400	1
Cleaver	CS-01	1
Alcohol Dispenser	PP	1
Manual Stripper	CF-02	1
USB Cable	-	1
Screw Driver	LD-3300	1

l OPTION PACKAGE

Category	Model
Battery	KF-3400
Electrode	EL-24
Cleaver Blade	BI-05
Work Belt	WB-01
Sleeving Clamp	SC-01
Fiber Holder	HS-250, HS-900, HS-2.5, HS-IN, HS-SC/FC, HF4-ST, HF4-LC, LS-900(Choose one)
Sleeve	S09-C, S09, S30-C, S30
Carrying Case	Hard Case(HC-11)
SOC Connector	SC, LC, FC, ST (Refer to FTTx Solution catalogue)
External Power	DC 12V Available for car cigar jack
Work Table	WK-02
Alcohol Dispenser	POM
