Máy test và kiểm tra tín hiệu cáp mạng POE NOYAFA NF-488
Technical indexes:
NF-488 Transmitter specification
Indictor
LCD 128x64 mm, with back light
Continulity function
Cable types
CAT5,CAT6
Check UTP/STP cable
YES
Cable short indicate
Max testing range
600m
Wire mapping
Emitter +Remote
Emitter + switch/routor
PoE function
Test range
DC5-60V POE switch
Standard identify
802.3af/at ( standard/non-standard)
Test range power
0-18W
Output interface
Power function
Voltage test range
DC0-60V
Current test range
0-3A
power test range
0-180W
Input voltage protection
DC48V 5mA
Max working current
≤80mA
Loopback
Compatible with 10M ,100M,1000M switch
Power supply
3*AAA
NF-488 Remote Specification
Ports
RJ45
Function
Wire mapping for network cable
770,000₫
3,900,000₫
26,000,000₫
3,195,000₫
3,500,000₫
2,200,000₫
2,500,000₫
Liên hệ
13,000,000₫
2,100,000₫
3,200,000₫
1,100,000₫
1,400,000₫
630,000₫
900,000₫
Chat với chúng tôi
9%
12%
10%
21%
30%
Mô tả
Máy test và kiểm tra tín hiệu cáp mạng POE NOYAFA NF-488
Technical indexes:
NF-488 Transmitter specification
Indictor
LCD 128x64 mm, with back light
Continulity function
Cable types
CAT5,CAT6
Check UTP/STP cable
YES
Cable short indicate
YES
Max testing range
600m
Wire mapping
Emitter +Remote
Emitter + switch/routor
PoE function
Test range
DC5-60V POE switch
Standard identify
802.3af/at ( standard/non-standard)
Test range power
0-18W
Output interface
YES
Power function
Voltage test range
DC0-60V
Current test range
0-3A
power test range
0-180W
Input voltage protection
DC48V 5mA
Max working current
≤80mA
Loopback
Compatible with 10M ,100M,1000M switch
Power supply
3*AAA
NF-488 Remote Specification
Ports
RJ45
Function
Wire mapping for network cable
Input voltage protection
DC48V 5mA
