Máy bơm keo tự động sử dụng khí nén RB3000D
Technical performance:
Air Source:
Max. 990kPa Non-lubricated dry air;
Operating Air Pressure:
20 ~ 690kPa;
Shot Time Range:
0.01 ~ 9.99sec. (Changeable to 0.1 ~ 99.9sec.);
Input Air Pressure:
2.5~8 bar(35-100 psi);
Output Air Pressure:
0.1~6.5 bar(1-90psi)
Vacuum Function:
Equipped: Adjustable with a dial;
Applicable Material Viscosity:
Low to High;
Repeat Accuracy:
±0.3%;
Dispensing Mode:
TIMED Mode: Fixed volume dispensing; STEADY Mode: Continuous dispensing;
Start Signal:
Foot switch or non-voltage N.O. contact input (Available to switch to voltage input by the inner dip switch);
Operation Speed:
Operation Circumstance:
160mm x 160mm x 70mm (Body);
68,000₫
85,000₫
Liên hệ
25,000₫
34,000₫
22,000₫
32,000₫
28,000₫
Chat với chúng tôi
20%
26%
31%
31%
21%
31%
Mô tả
Máy bơm keo tự động sử dụng khí nén RB3000D
Technical performance:
Air Source:
Max. 990kPa Non-lubricated dry air;
Operating Air Pressure:
20 ~ 690kPa;
Shot Time Range:
0.01 ~ 9.99sec. (Changeable to 0.1 ~ 99.9sec.);
Input Air Pressure:
2.5~8 bar(35-100 psi);
Output Air Pressure:
0.1~6.5 bar(1-90psi)
Vacuum Function:
Equipped: Adjustable with a dial;
Applicable Material Viscosity:
Low to High;
Repeat Accuracy:
±0.3%;
Dispensing Mode:
TIMED Mode: Fixed volume dispensing;
STEADY Mode: Continuous dispensing;
Start Signal:
Foot switch or non-voltage N.O. contact input
(Available to switch to voltage input by the inner dip switch);
Operation Speed:
Operation Circumstance:
160mm x 160mm x 70mm (Body);
