POE Fiber Switch - AES1204P-SFP - 4x10/100Base-T POE to 2x100Base-FX
Overview
AES1204P is 4 Port PoE 10/100M Fiber Switch provide 4 Port PoE (Power over Ethernet) which compliance with IEEE802.3af & IEEE802.3at standard; Let you simply connect IP camera / IP phone / Wireless AP at remote site where AC or DC power unavailable.
AES3204P also provide two Fiber Port can transmit data 0~120km from device to control center.
Features
4*RJ45 ports and 2*SFP sockets, convert Optical-Electric Ethernet signals between 10/100M UTP ports and 100M optical fiber ports
Each PoE port support IEEE 802.3af/at
Switch Ethernet signals between port and port.
Supports Auto MDI / MDI-X function
Flow control for full duplex and half duplex.
All SFP brands are supported; hot-plug supported
Technical Specifications
Standards
IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX IEEE802.3x Flow control and back pressure IEEE802.1d Spanning Tree IEEE802.3af/at POE
Performance
Processing Type: Store and Forward Back Bandwidth: 1.2Gbps MAC Address Size: 1024Kbit Packet Buffer Size: 512Kbit
Time Delay: <10us Frame: 2048bytes
Copper Port
Data Rate: 10/100M Connector: RJ45 x 4 Distance: 100m
Fiber Port
Data Rate: 155M Connector: SFP slot x 2 Distance: Up to SFP Transceivers
Mô tả
POE Fiber Switch - AES1204P-SFP - 4x10/100Base-T POE to 2x100Base-FX
Overview
AES1204P is 4 Port PoE 10/100M Fiber Switch provide 4 Port PoE (Power over Ethernet) which compliance with IEEE802.3af & IEEE802.3at standard; Let you simply connect IP camera / IP phone / Wireless AP at remote site where AC or DC power unavailable.
AES3204P also provide two Fiber Port can transmit data 0~120km from device to control center.
Features
4*RJ45 ports and 2*SFP sockets, convert Optical-Electric Ethernet signals between 10/100M UTP ports and 100M optical fiber ports
Each PoE port support IEEE 802.3af/at
Switch Ethernet signals between port and port.
Supports Auto MDI / MDI-X function
Flow control for full duplex and half duplex.
All SFP brands are supported; hot-plug supported
Technical Specifications
Standards
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE802.3x Flow control and back pressure IEEE802.1d Spanning Tree IEEE802.3af/at POE
Performance
Processing Type: Store and Forward Back Bandwidth: 1.2Gbps
MAC Address Size: 1024Kbit
Packet Buffer Size: 512Kbit
Time Delay: <10us Frame: 2048bytes
Copper Port
Data Rate: 10/100M Connector: RJ45 x 4 Distance: 100m
Fiber Port
Data Rate: 155M
Connector: SFP slot x 2
Distance: Up to SFP Transceivers
LED indicators
P: ON=Power Connected
F1: ON=Fiber 1 Connected; Active=Data Transmitting
F2: ON=Fiber 2 Connected; Active=Data Transmitting
POE: ON=Power Working; Off=No Power
L/A: ON=Copper Connected; Active= Data Transmitting
Power
Input Voltage: 12~56 VDC (PSE:48V)
Power Consumption: ≤6W
PoE Budget: 15.4Wx4=62W(PoE) 30Wx4=120W(PoE+)
Environment
Operating temperature : -10~65oC
Storage Temperature: -40~85oC
Relative Humidity: 5-95% (no condensation)
Physical Characteristics
Installation: Desk-top Dimension: 140*103*31mm Weight: 0.64kg
Order Information
Model No.
Description
AES1204P-SFP
10/100M 2FX4FE POE, SFP Slot; Ext.AC
